For further detailed information, please refer to the Instruction / User Manual Guide attached in the "Download Product Details" Section.
The main switch has 3 positions. To start the device set the button into position “AUTO”.
- AUTO (Automatic Start): The shredding operation will start automatically once the document to be shredded is inserted in the feed slot. The document shredder is set to normal operation. Please only insert the paper EVENLY into the feed slot otherwise a paper jam may result. After the paper has been fed into the shredding slot, the document shredder will deactivate automatically.
Only insert paper into the designated feed slots! - REV (Reverse Operation): “ REV” make the cutting unit turn backward. With these function paper jams can be removed (please refer to chapter “Protection against paper jams and overloading”).
- OFF position is recommended when emptying the wastebasket or when the shredder is not in use for a prolonged period of time.
Technical Specifications
|
Shred Type
|
Strip-Cut
|
|
Shred Size Paper (mm)
|
6 mm Particles
|
|
Shredding Capacity
|
6 pages DIN A4 (75g)
|
|
Shreds
|
Paper
|
|
Cutting speed
|
3.5 m/min
|
|
Feed Width (mm)
|
220 mm
|
|
Basket Capacity
|
7 Litres / 1.84 Gallons
|
|
Noise Level (dB)
|
Approx 72 dB
|
|
Unit Dimension (mm)
|
12.36 x 5.28 x 10.43 Inches 314 x 134 x 265 mm (WxDxH)
|
|
Voltage
|
AC 220V-240V 50Hz
|
|
Power Consumption
|
0.9 A
|
|
Unit Weight (kgs)
|
1.29 kgs |
RECOMMENDATIONS:
- For enhanced & better life of Paper Shredder, use Target LS-200 Lubricating/Oiling Sheets for Paper Shredders Pack of 10 after more than 50 pages to 200 pages shredding.
ATTENTION: The document shredder is not suitable for CDs/DVDs , shredding cassettes resp. diskettes.
